DV56-J1 Double Station Vise Top Tooling

R96-DV56-J1 Original price was: $1,612.00.Current price is: $1,369.00.
  • Medium-sized double station vise for 3-axis CNC machines.
  • Features independent jaw movement, reversible jaws, and the ability to fix the back jaw.
  • Maximizes efficiency for small to medium-sized parts.
  • Upgrade from traditional vises to a modular double station vise from 5th Axis.

Invest in the future of machining with our 5th Axis RockLock™ 96mm Quick Change Top Tooling System. Stay competitive, boost your productivity, and achieve exceptional results in your machining operations. Trust in our commitment to quality, precision, and innovation, and take your machining capabilities to new heights today. The R96-DV56-J1 is the optimal medium sized double station vise for 3-axis cnc machines. This unit features independent jaw movement, reversible jaws, and the ability to fix the back jaw. The DV56 allows for maximum small to medium part efficiency. Replace that old clunky traditional vise with a smaller and modular double station vise from 5th Axis.

File NameSize
3D Model254 KBDownload Now

Only 1 left in stock (can be backordered)

ADD TO QUOTE

Rocklock™

Time = Money

Reduce setup times by 80-95%.1

Swap Vises & Fixtures Quickly.

A standard mounting pattern allows for easy movement of vises, fixtures, and tooling from machine to machine no setup time.

High Accuracy

Patented free float design ensures equal force on all 4 pull studs guaranteeing repeatability of less than .0003″ (8 microns)

Standardize Your Setups.

Stop building custom adapters and subplates for every new job that comes into the shop. Job changeover becomes simple and repeatable with the RockLock™ system, saving you time and money.

Shop Now

Simplify Programming.

Established work offsets help speed up programming time when adjusting for different jobs and top tooling.

Shop Now

Easy Integration.

Pull studs are easily integrated into existing fixtures and subplates. Standard 52mm and 96mm spacing allow for compatability with competitive systems.

PS20F PULL STUD PRINT

Built To Last

All RockLock™ baseplates feature hardened steel rings and locking mechanisms. This ensures repeatability and wear resistance for the life of the product.

Smooth Operation

All units are operated via a simple allen wrench. The leadscrew only needs to be operated from one side, but has access from both sides; no reaching around your vise or parts.

FAQ

Consider your part size, machine table space, and automation needs. Use single-station vises for flexibility or double-station vises to maximize density.

No, 96mm top tooling is only compatible with 96mm RockLock™ bases. For 52mm systems, use the corresponding 52mm top tooling options.

The 96mm RockLock™ system provides ±0.005mm (±0.0002″) repeatability for high-precision applications.

The pull studs and the quick-change base must be from the same manufacturer, but the top tooling is interchangeable. The 96mm spacing, counter bore and thread size are common between competitive systems.
