Blank 6061 Aluminum Block

R96-BLANK $319.00
  • Machinable blank fixture crafted from aerospace-grade aluminum.
  • Enables customization of tooling or fixture for the 96mm RockLock™ quick-change system.

Invest in the future of machining with our 5th Axis RockLock™ 96mm Quick Change Top Tooling System. Stay competitive, boost your productivity, and achieve exceptional results in your machining operations. Trust in our commitment to quality, precision, and innovation, and take your machining capabilities to new heights today. The R96-Blank is a machinable blank fixture built from aerospace grade aluminum. This blank allows you to easily adapt custom tooling or make your own fixture for the 96mm RockLock™ quick-change system.

File Name Size
2D Drawing 110 KB Download Now
3D Model 29 KB Download Now

Only 11 left in stock (can be backordered)

Rocklock™

Time = Money

Reduce setup times by 80-95%.1

Swap Vises & Fixtures Quickly.

A standard mounting pattern allows for easy movement of vises, fixtures, and tooling from machine to machine no setup time.

High Accuracy

Patented free float design ensures equal force on all 4 pull studs guaranteeing repeatability of less than .0003″ (8 microns)

Standardize Your Setups.

Stop building custom adapters and subplates for every new job that comes into the shop. Job changeover becomes simple and repeatable with the RockLock™ system, saving you time and money.

Simplify Programming.

Established work offsets help speed up programming time when adjusting for different jobs and top tooling.

Easy Integration.

Pull studs are easily integrated into existing fixtures and subplates. Standard 52mm and 96mm spacing allow for compatability with competitive systems.

Built To Last

All RockLock™ baseplates feature hardened steel rings and locking mechanisms. This ensures repeatability and wear resistance for the life of the product.

Smooth Operation

All units are operated via a simple allen wrench. The leadscrew only needs to be operated from one side, but has access from both sides; no reaching around your vise or parts.

FAQ

Consider your part size, machine table space, and automation needs. Use single-station vises for flexibility or double-station vises to maximize density.

No, 96mm top tooling is only compatible with 96mm RockLock™ bases. For 52mm systems, use the corresponding 52mm top tooling options.

The 96mm RockLock™ system provides ±0.005mm (±0.0002″) repeatability for high-precision applications.

The pull studs and the quick-change base must be from the same manufacturer, but the top tooling is interchangeable. The 96mm spacing, counter bore and thread size are common between competitive systems.

No replacement parts available.
