Small Self-Centering Vise Top Tooling
R52-V75100X
$
1,153.00
Quantity
Small Self-Centering Vise Top Tooling quantity
Add to cart
Downloads
Specs
3D Model
User Manual
Dovetail Stock Prep & Troubleshooting Guide
Size:
75mm x 100mm x 56mm
Jaw Width:
75mm
Clamping Force:
22.0 kN @ 60 Nm
Max Torque:
60 Nm
Clamping Range (Jaws Forward):
0 – 40.3mm
Clamping Range (Jaws Reversed):
38.5mm – 76.3mm
Fixture:
V75100X
Pull Studs:
4x PS16F
Weight:
5 lbs
Suggested Products
V75100X-5
Master Hard Jaw
VAJ75X
Machinable 6061 Aluminum Jaws (Metric)
VSJ75X
Machinable 1018 Steel Jaws (Metric)
AL75S
Anti-Lift Jaws (Steel)
AL75A
Anti-Lift Jaws (Aluminum)
PS16F
52mm Pull Stud (Single)
